Weathershield, Socket, Single, Post Mount, 10A, 250VAC, IP54

Clipsal also offers the most compact weatherproofswitched outlet, small enough to mount onto 75mm2 columns.

The design includes a clear spring-loaded flap to ensure IP54 Rating when not in use.

The surface mounted version has a mounting box with 3 x 25mm plain entries (plugs fi tted) and a 25mm cut out in the base for back wiring.

Overall dimensions 65 x 78 x 87mm. Overall dimensions flush 65 x 78 x 54mm.

Terminals accommodate 4 x 2.5mm2 cables. Fixing screw caps and caps to cover mounting screws are provided.

Screw caps must be in place to ensure maximum IP Rating. Mines and Energy South Australia Approval S/1.

Available in Grey, White or Brown.
